Heating Temperature Control Block H Series
Product Features
・Heating block ・Used in combination with temperature controller TCD-200 EX
・Heating is possible up to the needle section by attaching a temperature control block nozzle tip (sold separately)
・Cord length: 1,000mm
・Heating is possible up to the needle section by attaching a temperature control block nozzle tip (sold separately)
・Cord length: 1,000mm
Product Specifications
| Item | H-05A | H-10A |
|---|---|---|
| Capacity | 5mL | 10mL |
| External Dimensions | (L)79×(D)33mm | (L)107×(D)34mm |
| Weight | 0.2kg | 0.23kg |
| Heater | Silicon rubber heater AC100V | |
| Sensor Used | Thermocouple (CA) 0-200°C | |
| Item | H-30A | H-50A |
|---|---|---|
| Capacity | 30mL | 50mL |
| External Dimensions | (L)125×(D)43mm | (L)157×(D)43mm |
| Weight | 0.33kg | 0.39kg |
| Heater | Silicon rubber heater AC100V | |
| Sensor Used | Thermocouple (CA) 0-200°C | |
※Maximum heating temperature for our plastic barrels is 50°C. Stainless steel barrels can be heated up to 200°C.
※HNG-01 temperature control block nozzle tip that attaches to the tip is sold separately.
※When ordering nozzle tips, please specify the size of the standard needle to be used.
※Barrel and adapter assembly are sold separately.
